24×16″ Standard Concentric Weld Reducer Carbon Steel

DIMENSIONAL DOCUMENT: STD CONC-ECC REDUCER

Description

OPV Part# WFCA24A16
Pipe Size: 24×16″
Fitting Type: CONC REDUCER
Material: CARBON STEEL
End Connection: BUTTWELD
Pipe Schedule: STD
Large End Outside Diameter: 24.00
Small End Outside Diameter: 16.00
Large End Inside Diameter: 23.25
Small End Inside Diameter: 15.25
Large End Wall Thickness  “T”: 0.375
Small End Wall Thickness “T”: 0.375
Length “L”: 20.00
Approx. Weight: 150.00
